Pressure pipe PVC-U PN10 liscio
Tubo a pressione PVC-U PN10 liscio UNI EN ISO 1452-2, Grigio RAL 7011, lunghezza 6m.
Pressure pipes for joint system by cold chemical welding (gluing through the use of suitable WELD-ON adhesive and detergent primer) or FORSHEDA 601 POWERLOCK® pre-inserted and locked gasket joint.
Lareter rigid PVC pipes for pressure pipes are guaranteed by the certifications issued by IIP, CSTB, DVGW, WRAS and IMO.
| Reference | D (mm) | S (mm) | Weight (kg/m) | Qty x pallet |
|---|---|---|---|---|
| PIPEV2103206L | 32 | 1.6 | 0.24 | 449 |
| PIPEV2104006L | 40 | 1.9 | 0.36 | 275 |
| PIPEV2105006L | 50 | 2.4 | 0.56 | 194 |
| PIPEV2106306L | 63 | 3 | 0.89 | 123 |
| PIPEV2107506L | 75 | 3.6 | 1.24 | 87 |
| PIPEV2109006L | 90 | 4.3 | 1.78 | 96 |
| PIPEV2611006L | 110 | 4.2 | 2.15 | 57 |
| PIPEV2612506L | 125 | 4.8 | 2.77 | 51 |
| PIPEV2614006L | 140 | 5.4 | 3.54 | 45 |
| PIPEV2616006L | 160 | 6.2 | 4.61 | 33 |
| PIPEV2618006L | 180 | 6.9 | 5.78 | 28 |
| PIPEV2620006L | 200 | 7.7 | 7.16 | 20 |
| PIPEV2622506L | 225 | 8.6 | 8.99 | 18 |
| PIPEV2625006L | 250 | 9.6 | 11.14 | 12 |
| PIPEV2628006L | 280 | 10.7 | 13.88 | 11 |
| PIPEV2631506L | 315 | 12.1 | 17.61 | 9 |
| PIPEV2635506L | 355 | 13.6 | 22.33 | 6 |
| PIPEV2640006L | 400 | 15.3 | 28.23 | 5 |
| PIPEV2650006L | 500 | 19.1 | 43.91 | 2 |
- Size range: d 16 - d 500 (mm)
- Nominal pressure: PN 6-10-12,5-16-20-25 with water at 20° C
- Temperature range: 0 °C ÷ 60 °C
- Coupling standards
- Solvent welding: EN ISO 15493, EN ISO 1452, DIN 8061/2.
- Coupling: Forsheda 601 POWER-LOCK® Gasket
- Reference standards
- Construction criteria: EN ISO 15493, EN ISO 1452, DIN 8061/2
- Test methods and requirements: EN ISO 15493, EN ISO 1452, DIN 8061/2
- Installation criteria: DVS 2204, DVS 2221, UNI 11242, EN ISO 1452, DIN 8061/2
- Pipe material: PVC-U dark grey RAL 7011
