MA3 - Double socket
PVC pressure fittings.
Double socket with solvent weld socket and BSP threaded female end
PVC (polyvinyl chloride) fittings for use in pressurised Irrigation Systems, water adduction, chemical installations and for water treatment in general.
| Reference | product.detail.attribute.D x G | PN | L1 | L2 |
Z | E | g |
|---|---|---|---|---|---|---|---|
| 1RMA316A00 | 16 x 3/8" | 16 | 14 | 11 | 6 | 24 | 12 |
| 1RMA320B00 | 20 x 1/2" | 16 | 16 | 15 | 4 | 29 | 20 |
| 1RMA325C00 | 25 x 3/4" | 16 | 19 | 16 | 5 | 35 | 30 |
| 1RMA332D00 | 32 x 1" | 16 | 22 | 19 | 6 | 43 | 48 |
| 1RMA340E00 | 40 x 1"1/4 | 16 | 26 | 21 | 5 | 50 | 56 |
| 1RMA350F00 | 50 x 1"1/2 | 16 | 31 | 21 | 8 | 61 | 102 |
| 1RMA363G00 | 63 x 2" | 16 | 38 | 26 | 8 | 76 | 181 |
- Size range:
-
- d 16 x 3/8" ÷ d 110 x 4"
- Nominal pressure:
- Imperial BS Series: Class E with water at 20°C up to d 4", Class D up to 6"
- BS/BSP transition fittings: Class E up to 2", Class D from 2"1/2 to 4"
- Temperature range: 0 °C ÷ 60 °C
- Reference standards:
- ISO 7-1, ISO 228-1
- Fitting material: PVC-U
- Seal material:
- Gaskets in EPDM, on request FKM
- Reinforcing rings (TM3, GM3, MM3, RM3) in stainless steel AISI 430
